Product Details
With a compact design, the Bath Bend Pop Down with Connector provides easy draining capability for your bath with a practical pop-up function.
Please Note:
– The Bath Bend Pop Down with Connector can be universally installed. However, the outlet size must be 40mm.
– The depth is adjustable for baths between 2-12mm in thickness. Additional screws may be required for baths thicker than 12mm.
Features:
– Compact top-fixing design
– Flexible connector (600mm in length)
– Self-lubricating/anti-jam acetal mechanism
– Innovative quick removal mechanism for drain access and cleaning
Dimensions:
– Height: 77mm
– Diameter: 73mm
– Flexible connector: (600mm in length)
– Maximum offset: 650mm
Browse our complete range of chrome wastes.
Shop Other Colour Options
Shop Other Colour Options
Product Info
Ease of Cleaning
Ease of Installation
.svg){kind=icon}
AEA (Advanced Electroplating Application)
| SKU | 16484 |
| Weight | .81kg |
| Brand | Art Australia |
| Construction | Solid Brass |
| Finish/Coating | Chrome – Advanced electroplating application (AEA) |
| Dimensions (mm) | Height: 77mm Diameter: 73mm Outlet: 40mm Flexible connector (600mm in length) Maximum offset: 650mm |
| Overflow | Yes |
| ETA | |
| COLOUR | Chrome |
| What's In The Box | 1 x Outer Body (ABS) 1 x Pop Down Mechanism 1 x Inner Body 1 x Rubber Double Seal 1 x Flexible Tube (PVC 600mm) 1 x Outlet (ABS) 2 x M5 Adjustment Bolts |
Specification guides can be found under the Downloads tab.
Product Documents
| Bath Bend Pop Down - Info Sheet |  |
Bim Files
| View Library | |
Product FAQs
Does this pop-up waste have an overflow?
Yes, this pop-up waste has both an overflow and non-overflow functionality.
What type of coating is used on this product?
This product uses Advanced Electroplating Application Coating System (AEA).
AEA is a process that uses electrical current to plate one metal upon another metallic surface to create a long-lasting and durable finish.
How does the plug and waste function?
The waste has a simple push function. Simply press down on the waste to prevent the water from draining, and press again to pop the waste up, allowing the water to drain. The water won’t drain out when the waste is pressed down.
What size hole can this waste be used for?
This pop-up waste is designed to fit a hole size of 40mm.
